PCI Serial Parallel Combo Card with Dual Serial RS232 Ports (DB9) & 1x Parallel LPT Port (DB25) - PCI Combo Adapter Card - PCI Expansion Card Controller - PCI to Printer Card

Specifications & Compliance

UPC

065030891301

Brand

StarTech.com

Included in Package

1 - PCI Serial Parallel Combo Card, 1 - Full Profile Bracket (Installed), 2 - Low Profile Brackets (for Serial Ports), 1 - Low Profile Bracket (for Parallel Port), 1 - Quick-Start Guide

Shipping (Package) Weight

6.7 oz [190 g]

Weight of Product

5.0 oz [141.0 g]

Product Length

5.3 in [13.4 cm]

Product Width

0.9 in [21.6 mm]

Product Height

4.7 in [12.0 cm]

Package Depth

5.6 in [14.3 cm]

Package Width

6.9 in [17.4 cm]

Package Height

1.3 in [33 mm]

Color

Black

Warranty

Lifetime

Connector 1

PCI / PCI-X

Connector 1 (Quantity)

1

Package Quantity

1

Connector 2

DB-9 Serial

Connector 2 (Quantity)

2

Operating Temperature

0°C to 70°C (32°F to 158°F)

Storage Temperature

-20°C to 85°C (-4°F to 185°F)

Humidity

10~90% RH

Maximum Data Transfer Rate

Serial - 115.2Kbps<br> Parallel - 1.5Mbps

Industry Standards

IEEE 1284, 16C550 (RS-232)

Chipset ID

Asix - MCS9865

Connector 3

DB-25 Parallel / Serial

Connector 3 (Quantity)

1

Number of Ports

3

Interface

PCI / PCI-X (5 / 3.3V)

Bus Type

PCI

Card Type

Standard Profile (LP bracket incl.)

Port Style

Integrated on Card

Serial Protocol

RS-232

Max Baud Rate

115.2 Kbps

FIFO

256 Bytes

Data Bits

5, 6, 7, 8, 9

Flow Control

None, Xon/Xoff, RTS/CTS

Parity

None, Odd, Even, Space, Mark

Stop Bits

1, 1.5, 2
