LEESON Direct Drive Blower Motor: Single Phase, Yoke, Permanent Split Capacitor, 1/3 hp Horsepower

Specifications & Compliance

Manufacturer #

191871.00

Brand

LEESON

Nameplate Horsepower @ 60 Hz

1/3 hp

Nameplate RPM @ 60 Hz

1,625 RPM

Frame Size

48

Nameplate Voltage @ 60 Hz

115/230V AC

Full Load Amps @ 60 Hz

1.7 A

Enclosure Type

TENV

Motor Thermal Protection

Auto

Nameplate Service Factor @ 60 Hz

1

Shaft Diameter

1/2 in

Shaft Length

2-1/2 in

Output Shaft (Dia x L)

1/2 in x 2-1/2 in

Phase

Single

Mounting Type

Yoke

Body Diameter

5.6 in

Motor Shaft Rotation

CW/CCW

Frequency

60 Hz

Usable @ 208V

Not Usable at 208V
