4-Port Managed USB Hub with 4x USB-A, Heavy Duty with Metal Industrial Housing, ESD & Surge Protection, Wall/Desk/Din-Rail Mountable, USB 3.0/3.1/3.2 Gen 1 5Gbps - TAA

$193.99

Connect and manage up to four USB Type-A devices, using this USB hub - designed for industrial/commercial environments

SKU: 5G4AINDRM-USB-A-HUB Category:

Specifications & Compliance

UPC
065030898188
Brand
StarTech.com
Included in Package
1 - USB Hub, 1 - 6 ft [1.8 m] USB-A to USB-B Cable, 1 - Terminal Block Connector (Attached), 1 - DIN Rail Mounting Bracket (with M3 Mounting Screws), 1 - Quick-Start Guide
Shipping (Package) Weight
14.7 oz [416 g]
Weight of Product
7.1 oz [202.0 g]
Product Length
2.3 in [57.2 mm]
Product Width
4.5 in [11.5 cm]
Product Height
1.0 in [26.1 mm]
Package Depth
5.9 in [15 cm]
Package Width
8.5 in [21.6 cm]
Package Height
2.2 in [55 mm]
Color
Black
Warranty
2 Years
Connector 1
USB-A (5Gbps, 7.5W)
Connector 1 (Quantity)
3
Package Quantity
1
Connector 2
USB-A (5Gbps, 4.5W)
Connector 2 (Quantity)
1
Operating Temperature
0°C to 60°C (32°F to 140°F)
Storage Temperature
-20°C to 75°C (-4°F to 167°F)
Humidity
5 to 95% RH
Material
Metal
Maximum Data Transfer Rate
5 Gbps (USB 3.2 Gen 1)
Industry Standards
USB Battery Charging Specification Rev. 1.2 <br /> USB 3.2 Gen 1 - Backwards compatible with USB 3.0, 2.0, and 1.1
Power Source
Not Included (DC/Terminal Block)
Chipset ID
VIA - VL817-Q7 C0
Special Notes
- The top-right USB port supports 4.5W (5V/0.9A) of power, and will only support 5Gbps USB devices; It is not compatible with USB 2.0 (480Mbps). See Quick-Start Guide for details.
MTBF
131,406 Hours
LED Indicators
4 - USB Port Status LEDs (Green) - The Corresponding USB-A Data/Charge Port is Enabled or Disabled, 1 - Power LED (Green) - The USB Hub is receiving power
Number of Ports
4
Interface
USB 3.2 Gen 1 (5Gbps)
Type and Rate
USB 5Gbps
System and Cable Requirements
- Available USB 3.2 Gen 1 Port, - USB 3.2 Gen 1 (5 Gbps) is also know as SuperSpeed USB, USB 3.1 Gen 1, and USB 3.0, - DC Power Source +7 to 48V, <br>
Host Connector 1
USB-B (5Gbps, 4.5W)
Host Connector 1 (Quantity)
1
Plug Type
Terminal Block (2 Wire)
UASP Support
Yes
Mounting Options
DIN Rail
Fast-Charge Port(s)
Yes
Form Factor
Industrial
USB-C Host Connection
No
USB-C Device Port(s)
No
Total Available Power Output
35W
Number of Battery Charge 1.2 Ports
3
Device Power Consumption
41 Watts
ESD Protection
+/-15kV (Air), +/-8kV (Contact)
