1U 17" Rackmount LCD Console with Integrated 16 Port IP KVM Switch

1U 17" Rackmount LCD Console with Integrated 16 Port IP KVM Switch

$2,555.99

Control 16 servers or KVM switches remotely over an IP network with this rack mountable LCD console

SKU: CABCONS1716I Category:

Specifications & Compliance

UPC
065030830492
Brand
StarTech.com
Included in Package
1 - Cabinet console, 2 - Rack mount brackets, 1 - Power plug, 1 - Power adapter
Shipping (Package) Weight
38.6 lb [17.5 kg]
Weight of Product
0.0 oz [0.0 g]
Product Length
0.0 in [0.0 mm]
Package Depth
24.7 in [62.8 cm]
Package Width
21.7 in [55 cm]
Package Height
8.0 in [20.2 cm]
Color
Black
Warranty
3 Years
Connector 1
RJ-45
Connector 1 (Quantity)
1
Package Quantity
1
Connector 2
VGA
Connector 2 (Quantity)
1
Material
Heavy Duty Steel
Industry Standards
VESA DDC 1/2B, VESA DPMS compliant
Power Source
AC Adapter Included
Special Notes
<p>Adding more than 1 optional PCM815SHNA power switch to the Server Remote Control requires a <a href="http://www.startech.com/Product/ItemDetail.aspx?productid=RPORT&c=CA" target=new>RPORT</a> module.</p> <p>Source code for the unit operating system is available upon request. Please contact us by phone, live chat, or email to make your request. </p> <p>This offer is valid for three years from the date of purchase and/or for as long as parts or customer support is offered for this product.</p> <p>Charges for the reasonable cost of copying and/or conveying may apply.</p>
Input Voltage
100 - 240 AC
Output Voltage
12V DC
Connector 3
PS/2
Connector 3 (Quantity)
2
Power Consumption
48
MTBF
445,400 Hours
Input Current
1.8A
Output Current
4
Host Connector 1
VGA
Host Connector 1 (Quantity)
16
Audio
No
Plug Type
M
Center Tip Polarity
Positive
Connector 4
DB-9 Serial
Connector 4 (Quantity)
1
Maximum Analog Resolutions
1280x1024
Cascadable
Yes
Rack-Mountable
Yes
U Height
1U
Number of KVM Ports
16
IP Control
Yes
Supported Platforms
USB and PS/2
PC Video Type
VGA
Number of Monitors Supported
1
On-Screen Display
Yes
Port Selection Support
Hotkeys and OSD (On Screen Display)
Maximum Number of Users
1 Local, 4 Remote
Aspect Ratio
4:3
Front Door Key Lock
No
Display Size
17"

Questions & Answers

What DC barrel connector power plug types do StarTech.com products use, and what are their dimensions?
StarTech.com DC barrel connector plug types are defined in the “Plug Type” field of the technical specifications, using a letter code that specifies the connector’s outer diameter (OD) and inner diameter (ID) in millimeters for power adapter compatibility. Explanation: In StarTech.com technical specifications, the “Plug Type” field is a standardized identifier for the exact DC barrel connector size required to power a product. Each plug type is assigned a letter code that corresponds to a specific combination of outer diameter (OD) and inner diameter (ID), measured in millimeters. Common DC barrel plug type dimensions Plug Type OD ID A 2.35 mm 0.7 mm B 4.0 mm 1.7 mm C 4.75 mm 1.7 mm H 3.4 mm 1.3 mm L 5.0 mm 2.5 mm M 5.5 mm 2.1 mm N 5.5 mm 2.5 mm The DC barrel connector plug type must match both the outer diameter and inner diameter exactly. A mismatch between the StarTech.com product requirement and the power adapter connector can prevent proper fit or stable power delivery, which may result in device startup failure or intermittent operation. The plug type defines only the physical connector size. The plug type does not define electrical power requirements such as voltage, current, or polarity. The power adapter used with a StarTech.com product must match the product’s specified electrical requirements. Using an incompatible power adapter can cause device malfunction or permanent damage. This standardized DC barrel connector plug type system enables IT professionals and procurement teams to verify connector dimensions, ensure power adapter compatibility, standardize hardware deployments, and identify the correct replacement power supply for StarTech.com products.
