1U 15" Rackmount LCD Console - USB + PS/2

1U 15" Rackmount LCD Console - USB + PS/2

$836.99

Centralized control of a server or KVM switch with this 1U USB PS/2 rack-mountable LCD console

SKU: RACKCONS1501 Category:

Specifications & Compliance

UPC
065030822183
Brand
StarTech.com
Included in Package
1 - 1U LCD Rack Console Drawer (1), 1 - Mounting Rails - Set (1), 1 - Console Cable Kit (1), 1 - Power Adapter (1)
Shipping (Package) Weight
36.6 lb [16.6 kg]
Weight of Product
24.3 lb [11.0 kg]
Product Length
20.9 in [53.0 cm]
Product Width
18.9 in [48.1 cm]
Product Height
1.8 in [45.0 mm]
Package Depth
26.2 in [66.5 cm]
Package Width
22.4 in [56.8 cm]
Package Height
8.3 in [21 cm]
Color
Black
Warranty
2 Years
Connector 1
VGA
Connector 1 (Quantity)
1
Package Quantity
1
Connector 2
USB-A (480Mbps, 2.5W)
Connector 2 (Quantity)
1
Operating Temperature
0°C to 50°C (32°F to 122°F)
Storage Temperature
-20°C to 60°C (-4°F to 140°F)
Material
Heavy Duty Steel
Power Source
Standard 120V Power Cords
Input Voltage
110V-240V AC
Connector 3
PS/2
Connector 3 (Quantity)
2
Power Consumption
16
MTBF
60,000 Hours
Audio
No
Maximum Analog Resolutions
1280x1024 @ 85Hz
Cascadable
Yes
Rack-Mountable
Yes
Number of KVM Ports
1
IP Control
No
Supported Platforms
USB and PS/2
PC Video Type
VGA
Number of Monitors Supported
1
On-Screen Display
Yes
Port Selection Support
Hotkeys and OSD (On Screen Display)
Maximum Mounting Depth
31.5 in [80 cm]
Maximum Number of Users
1
Aspect Ratio
4:3
Minimum Mounting Depth
21.7 in [55 cm]
Front Door Key Lock
Yes
Display Size
15"

Questions & Answers

Everything is hooked up but nothing is working. What should I do?
When you troubleshoot issues with a rack console, there are some quick tests that you can complete to rule out potential problems. You can test to make sure that the following components are working correctly and are not the source of the issue: Video cables Video source Monitor USB/PS2 cables Before you test the components, make sure that the rack console is properly mounted to a rack. For more information, see the documentation that came with the rack console. To test your setup components, try the following: Use the video cables, video source, monitor, and USB/PS2 cable(s) in another setup to see if the problem is with the components or the setup. Use a different video cable, video source, monitor, and USB/PS2 cable(s) in your setup to see if the problem persists. Ideally, you should test a component that you know works in another setup. Note: When testing with a different keyboard, mouse, and monitor, connect the devices directly to your computer. When you test your cables, it is recommended that you do the following: Test each cable individually. Use short cables, with the least amount of adapters. When you test the video cables, video source, and monitor, it is recommended that you do the following: Use a resolution that is compatible with the monitor and any KVM switches that you may use. When a KVM switch is used with the rack console, make sure that you selected the correct source. If some of the sources are working but not others, you may be experiencing issues with the KVM switch in your setup. For more information, see the KVM Troubleshooting FAQ.
