Electronic Fluorescent Ballasts
Electronic fluorescent ballasts replace burnt-out electronic or magnetic ballasts in fluorescent lighting fixtures. They are more energy efficient than magnetic ballasts and do not hum or cause lights to flicker. Electronic ballasts protect from damaging power fluctuations that affect the lamp's output quality. They provide an initial voltage spike to turn on the lamps, then regulate the voltage and current and protect them from power fluctuations. Replacement ballasts should have the same voltage and start type as the old ballast, fit into the fixture, and be able to power the number and type of lamps used in the fixture.
-
4ZZ33
ADVANCE CFL Ballast: 120 to 277V AC, 1/2 Lamps Supported, 16 W Bulb Watt, 4 1/4 in Overall Lg
Number of Lamps Supported: 2; 1 · Input Voltage: 120 to 277V AC · Ballast Bulb Type: PL-S; PL-L; PL-T; PL-Q · Bulb Wattage: 16 W
-
4ZZ34
ADVANCE CFL Ballast: 120 to 277V AC, 1/2 Lamps Supported, 18 W Bulb Watt, 4 1/4 in Overall Lg
Number of Lamps Supported: 2; 1 · Input Voltage: 120 to 277V AC · Ballast Bulb Type: PL-Q · Bulb Wattage: 18 W
-
5YG67
ADVANCE CFL Ballast: 120 to 277V AC, 1/2 Lamps Supported, 26 W_28 W_32 W_38 W_42 W Bulb Watt
Number of Lamps Supported: 1; 2 · Input Voltage: 120 to 277V AC · Ballast Bulb Type: PL-T · Bulb Wattage: 32 W; 28 W; 26 W; 42 W; 38 W
-
4ZZ35
ADVANCE CFL Ballast: 120 to 277V AC, 1/2 Lamps Supported, 32 W_42 W Bulb Watt, 4 1/4 in Overall Lg
Number of Lamps Supported: 2; 1 · Input Voltage: 120 to 277V AC · Ballast Bulb Type: CFQ; CFT; CFS · Bulb Wattage: 42 W; 32 W
-
1XWJ5
ADVANCE CFL Ballast: 120 to 277V AC, 1/2 Lamps Supported, 40 W Bulb Watt, 9 1/2 in Overall Lg
Number of Lamps Supported: 1; 2 · Input Voltage: 120 to 277V AC · Ballast Bulb Type: PL-L · Bulb Wattage: 40 W
-
1XWJ6
ADVANCE CFL Ballast: 120 to 277V AC, 2/3 Lamps Supported, 40 W Bulb Watt, 9 1/2 in Overall Lg
Number of Lamps Supported: 3; 2 · Input Voltage: 120 to 277V AC · Ballast Bulb Type: PL-L · Bulb Wattage: 40 W
-
796NX4
ADVANCE Electronic Ballast: 120 to 277V AC, 1 Lamps Supported, 32 W Bulb Watt, 9 1/2 in Overall Lg
Number of Lamps Supported: 1 · Input Voltage: 120 to 277V AC · Ballast Bulb Type: T8 · Bulb Wattage: 32 W
-
796NX6
ADVANCE Electronic Ballast: 120 to 277V AC, 2 Lamps Supported, 32 W Bulb Watt, 9 1/2 in Overall Lg
Number of Lamps Supported: 2 · Input Voltage: 120 to 277V AC · Ballast Bulb Type: T8 · Bulb Wattage: 32 W
-
796NX7
ADVANCE Electronic Ballast: 120 to 277V AC, 2 Lamps Supported, 32 W Bulb Watt, 9 1/2 in Overall Lg
Number of Lamps Supported: 2 · Input Voltage: 120 to 277V AC · Ballast Bulb Type: T8 · Bulb Wattage: 32 W
-
796NX8
ADVANCE Electronic Ballast: 120 to 277V AC, 2 Lamps Supported, 54 W Bulb Watt, 9 1/2 in Overall Lg
Number of Lamps Supported: 2 · Input Voltage: 120 to 277V AC · Ballast Bulb Type: T5HO · Bulb Wattage: 54 W
