U.S. MOTORS General Purpose Motor: Single Phase, 1/2 hp, 115/208-230V AC, 56 Frame Size, 1,725 RPM

Specifications & Compliance

Manufacturer #

T12CM2J

Brand

U.S. MOTORS

Nameplate Horsepower @ 60 Hz

1/2 hp

Nameplate RPM @ 60 Hz

1,725 RPM

Frame Size

56

Nameplate Voltage @ 60 Hz

115/208-230V AC

Full Load Amps @ 60 Hz

9.0/4.3-4.5 A

Motor Enclosure Type(Abbreviated)

TEFC

Motor Thermal Protection

Manual

Nameplate Service Factor @ 60 Hz

1.15

Output Shaft (Dia x L)

5/8 in x 1-15/16 in

Phase

Single

Frequency

60 Hz

Insulation Class

B

Shaft Diameter

5/8 in

Shaft Length

1-15/16 in

Motor Design

Capacitor-Start

Mounting Type

Rigid Base

Motor Enclosure Type

Totally Enclosed Fan Cooled

Motor Shaft Rotation

CW/CCW

Nominal Efficiency

60.7 %

Number of Speeds

1

Efficiency Rating

Standard Efficiency (IE1)
