LEESON General Purpose Motor: Single Phase, 3/4 hp, 115/230V AC, 56C Frame Size, 1,725 RPM, 60 Hz, F

Specifications & Compliance

Manufacturer #

056C17D11041

Brand

LEESON

Nameplate Horsepower @ 60 Hz

3/4 hp

Nameplate RPM @ 60 Hz

1,725 RPM

Frame Size

56C

Nameplate Voltage @ 60 Hz

115/230V AC

Full Load Amps @ 60 Hz

10.9/5.4 A

Motor Enclosure Type(Abbreviated)

ODP

Motor Thermal Protection

None

Nameplate Service Factor @ 60 Hz

1.25

Phase

Single

Frequency

60 Hz

Insulation Class

F

Motor Design

Capacitor-Start

Mounting Type

C-Face; Rigid Base

Motor Enclosure Type

Open Drip Proof

Motor Shaft Rotation

CW/CCW

Nominal Efficiency

68.8 %

Number of Speeds

1

Efficiency Rating

Standard Efficiency (IE1)
