LEESON Agricultural Fan Motor: Single Phase, Cradle Base, Permanent Split Capacitor, 1/2 hp, Auto, B

Specifications & Compliance

Manufacturer #

5KCP36NNB059S

Brand

LEESON

Nameplate Horsepower @ 60 Hz

1/2 hp

Nameplate RPM @ 60 Hz

1,075 RPM

Frame Size

48Z

Nameplate Voltage @ 60 Hz

115/230V AC

Full Load Amps @ 60 Hz

7.2/3.6 A

Motor Enclosure

TENV

Motor Thermal Protection

Auto

Nameplate Service Factor @ 60 Hz

1

Output Shaft (Dia x L)

1/2 in x 2-1/2 in

Mounting Type

Cradle Base

Motor Design

Permanent Split Capacitor
