BALDOR General Purpose Motor: Single Phase, 5 hp, 230V AC, 213T Frame Size, 1 3/8 in x 3 3/8 in, F

Specifications & Compliance

Manufacturer #

L1508T

Brand

BALDOR

Nameplate Horsepower @ 60 Hz

5 hp

Nameplate RPM @ 60 Hz

1,800 RPM

Frame Size

213T

Nameplate Voltage @ 60 Hz

230V AC

Full Load Amps @ 60 Hz

27.0 A

Motor Enclosure Type(Abbreviated)

ODP

Motor Thermal Protection

None

Nameplate Service Factor @ 60 Hz

1.15

Output Shaft (Dia x L)

1-3/8 in x 3-3/8 in

Phase

Single

Frequency

60 Hz

Insulation Class

F

Shaft Diameter

1-3/8 in

Shaft Length

3-3/8 in

Motor Design

Capacitor-Start/Run

Mounting Type

Rigid Base

Motor Enclosure Type

Open Drip Proof

Motor Shaft Rotation

CW/CCW

Nominal Efficiency

77 %

Number of Speeds

1

Efficiency Rating

High Efficiency (IE2)
