5 Port Unmanaged Energy-Efficient Gigabit Ethernet Switch - Desktop / Wall Mount Network Switch

5 Port Unmanaged Energy-Efficient Gigabit Ethernet Switch - Desktop / Wall Mount Network Switch

$34.99

Network up to 5 Ethernet devices through a single, energy-efficient Gigabit desktop switch - Wall Mountable

SKU: DS51002 Category:

Specifications & Compliance

UPC
065030854610
Brand
StarTech.com
Included in Package
1 - Ethernet Switch, 1 - Power Adapter, 1 - Instruction Manual
Shipping (Package) Weight
11.3 oz [319 g]
Weight of Product
4.0 oz [114.0 g]
Product Length
5.5 in [14.0 cm]
Product Width
3.5 in [90.0 mm]
Product Height
1.0 in [25.0 mm]
Package Depth
6.6 in [16.8 cm]
Package Width
8.1 in [20.7 cm]
Package Height
2.6 in [65 mm]
Color
Black
Warranty
2 Years
Connector 1
RJ-45
Connector 1 (Quantity)
5
Operating Temperature
0°C to 40°C (32°F to 104°F)
Storage Temperature
-40°C to 70°C (-40°F to 158°F)
Humidity
10~90% RH (Non-Condensing)
Material
Plastic
Maximum Data Transfer Rate
2 Gbps (Full-Duplex)
Industry Standards
IEEE 802.3 10BASE-T, IEEE 802.3u 100BASE-TX, IEEE 802.3ab 1000BASE-T, IEEE 802.3az Energy-Efficient Ethernet
Power Source
AC Adapter Included
Input Voltage
110V-240V AC
Output Voltage
5 DC
LED Indicators
1 - Power, 5 - Link / Act
Number of Ports
5
Input Current
0.3 A
Output Current
0.6
Plug Type
H
Compatible Networks
10/100/1000 Mbps
Center Tip Polarity
Positive
General Specifications
Power adapter specifications refer to DS51002 rev. 2. Prior to rev. 2, the DS51002 power adapter specifications included: 9V output voltage, 0.6A output current, and M plug type.
Auto MDIX
Yes
Full Duplex Support
Yes
Flow Control
Half-duplex back-pressure and IEEE802.3x full-duplex
Switching Architecture
Store-and-Forward

Questions & Answers

What DC barrel connector power plug types do StarTech.com products use, and what are their dimensions?
StarTech.com DC barrel connector plug types are defined in the “Plug Type” field of the technical specifications, using a letter code that specifies the connector’s outer diameter (OD) and inner diameter (ID) in millimeters for power adapter compatibility. Explanation: In StarTech.com technical specifications, the “Plug Type” field is a standardized identifier for the exact DC barrel connector size required to power a product. Each plug type is assigned a letter code that corresponds to a specific combination of outer diameter (OD) and inner diameter (ID), measured in millimeters. Common DC barrel plug type dimensions Plug Type OD ID A 2.35 mm 0.7 mm B 4.0 mm 1.7 mm C 4.75 mm 1.7 mm H 3.4 mm 1.3 mm L 5.0 mm 2.5 mm M 5.5 mm 2.1 mm N 5.5 mm 2.5 mm The DC barrel connector plug type must match both the outer diameter and inner diameter exactly. A mismatch between the StarTech.com product requirement and the power adapter connector can prevent proper fit or stable power delivery, which may result in device startup failure or intermittent operation. The plug type defines only the physical connector size. The plug type does not define electrical power requirements such as voltage, current, or polarity. The power adapter used with a StarTech.com product must match the product’s specified electrical requirements. Using an incompatible power adapter can cause device malfunction or permanent damage. This standardized DC barrel connector plug type system enables IT professionals and procurement teams to verify connector dimensions, ensure power adapter compatibility, standardize hardware deployments, and identify the correct replacement power supply for StarTech.com products.
